“14.95 m Pilot Bot” | |
Endaze Project No : | EP179 |
Name : | - |
Shipyard : | ALMAR |
Owner : | - |
Classification : | - |
Main Dimensions | |
Length : | 14.95 m |
Breadth : | 4.70 m |
Depth : | 2.53 m |
Draught : | 1.10 m |
Speed : | 22.00 knot |
Propulsion : | Propeller , Diameter =900 mm |
Hull Material : | Steel |
S.S. Material : | Aluminum Alloy AA5083 |
Main Engine Power : | 2 x CUMMINS QSM11 610 HP |
Aux. Generator : | WESTERBEKE 12 EDT 12KW 50 HZ 1500 RPM |
Other : | 2 Crew , 6 Passengers |
Scope | |
Conceptual | ENDAZE |
Consulting | ENDAZE |
Basic Design | ENDAZE |
Structural Detailed Design | ENDAZE |
Machinery and Piping Detailed Design | ENDAZE |
Engineering Calculations | ENDAZE |
Production | ENDAZE |
Links | |
EP179 14.95 m Pilot Bot
PHOTOS
